vSphere Data Collector
iTop Hub
PHP 8.1

This stand-alone application collects information about a whole data center from a vSphere server (using the vSphere Web Services) and synchronizes this information with iTop using several Synchronization Data Sources.

vSphere Data Collector connections


  • Automated inventory of Servers (with their Brand, Model), Hypervisors (with their OS Family and OS Version), Farms, Virtual Machines (with their OS Family and OS Version).
  • Optional inventory of IPv4 addresses and logical interfaces
  • The collector can reside on any system with web access to both vSphere Web Services and iTop.
  • Automatic creation and update of the Synchronization Data Sources in iTop.
  • Starting with version 1.0.12 the collection mechanism is somehow extensible
This collector makes use of iTop's built-in Data Synchronization mechanism. For more information about how the data synchronization works, refer to Data Synchronization Overview and relies on Data collector Base mechanism

Revision History

Release Date Version Comments
2023-03-10 1.1.0 * Prevent a PHP Warning when there is no custom_synchro definition
* Trace the hypervisor software and API version (in DEBUG)
* Accept E1000E network devices (thanks to @rudnerbjoern)
* N°5067 - Cleanup RestClient::GetFullSynchroDataSource() (thanks to @Hipska)
* N°5707 - Contact to notify can also be a Team (thanks to @Hipska)
* N°5868 - Add PHP 8.0 / 8.1 compatibility (collector base)
* N°5868 - Add PHP 8.0 / 8.1 compatibility (vSphere collector)
* N°5884 - Missing attributes in aSkippedAttribute
* N°5950 - cleanup code and fix some futurs bugs in php 8.2
* N°5979 - Remove PHP warning and hide test data collectors in iTop setup
* N°5995 - Fix PHP warning on lookup when table is empty
* N°6093 - Remove friendlyname in JSON configuration as it is no longer returned by iTop
2020-12-21 1.0.16 Fix compatibility with SSO set as default connection mode
2020-10-20 1.0.14 - Fix PHP Fatal error: Uncaught Error: Class IOException not found
2020-07-07 1.0.13 - Differenciates error/logs between teemip NOT installed and itop REST API issue
- Multi configuration file
- New CSV collector
- Configurable timestamp added in the logs
- New option for usage: –help
2020-04-02 1.0.12 - Made the Server and Hypervisor collectors configurable
- Fix for a crash caused by a blank datastore name (thanks to David Wißen from ITOMIG for reporting it).
- Fix for some OpenVM Tools reporting IP addresses with a trailing space (thanks to Martin Raenker from ITOMIG).
2018-12-31 1.0.11 Corrects regression introduced by 1.0.10 :
- Improved support of iTop 2.4+ (obsolescence flag)
- Removed a debug trace
- Fix Virtual machines which “connectionState” is not “connected” are skipped
  2018-08-24 1.0.10 Handles TeemIp :
- Automatically detects if TeemIp (as an iTop module or as a standalone application) is present.
- Optional synchronization of IPv4 addresses
- Optional synchronisation of logical interfaces
2018-07-02 1.0.9 Robustness :
- more traces in debug mode (–console_log_level=9)
- skipping virtual machines which “connectionState” is not “connected”, since most of their properties are not accessible and would crash PHP/Soap (with a core dump !!)
2018-02-22 1.0.8 - The os_version_mapping was used only for Hypervisors, made it work for VirtualMachines also.
Proper support of UTF-8 characters in regular expressions (the code now always uses the u modifier)
2017-04-24 1.0.7 Fixed the value for the status of VMs: 'production' instead of 'active'.
2017-03-08 1.0.6 - Code cleanup.
- Data Synchro status and full_load_interval are now homogeneous and configurable parameters for all data sources.
- OS Version and OS Family have their own mapping table.
- Fix for the Hypervisor status value (now defaults to “production”).
- Addition of the check_soap.php script for troubleshooting.
- Protect against a PHP crash in case of a disconnected ESX.
- Do not collect an IPV6 as the management IP address of a virtual machine (since the field can only contain an IPV4). Many thanks to Andrew Armstrong for proposing this fix.
2016-12-08 1.0.5 New options to bypass SSL certificate validation and automatic detection of invalid certificates.
2015-11-16 1.0.4 Replace line-breaks by spaces inside the description of a VM. Fix the +1 on the number of vCPUs
2015-04-17 1.0.3 Added the collection of the “description” field for a VM
2015-02-23 1.0.2 Servers must be loaded before hypervisors
2015-01-07 1.0.1 Beta version
2014-05-13 1.0.0 First alpha version


Data-Collector-for-VSphere is not working on vCenter 7.0.0. If you are using php version lower than php-7.3.24 or php-7.4.12

This version of the collector does not collect the Data Stores (they do not exist in the iTop standard data model). Logical interfaces may be collected in the case where TeemIp (module or standalone) is used.

If IP collection is enabled, only IPv4 addresses are collected, not IPv6.

The current version of the collector is designed to collect information from a single vSphere server. To collect and reconcile information form several vSphere servers into one iTop, check the section Collecting from several vSphere servers below.


  • PHP Version 5.3.0 (support of namespaces is required for the vSphere API library)
  • An access to the vSphere web services API
  • An access to the iTop web services (REST + synchro_import.php and synchro_exec.php)
  • + Data collector Base requirements.


Do not install this extension in your webserver directories (like apache). otherwise your configuration files (with URLs, credentials) may be accessible from outside
  • Expand the content of the zip archive on a folder on the machine that will run the collector application. This machine must have a web access to both the vSphere server and the iTop server.
  • Edit the content of the file conf/params.local.xml to suit your installation, supplying the appropriate credentials to connect to vSphere and iTop.


For example create the file params.local.xml in the conf directory with the following XML content:

<?xml version="1.0" encoding="UTF-8"?>
Parameter Meaning Sample value
itop_url URL to the iTop Application https://localhost/itop
itop_login Login (user account) for connecting to iTop. Must have admin rights for executing the data synchro. admin
itop_password Password for the iTop account.
vsphere_uri The address/port to connect to vSphere. Format: <name>:<port> or <ip_address>:<port>
vsphere_login Login for connecting to vSphere administrateur
vsphere_password Password corresponding to the vSphere login
vsphere_connection_options List of PHP Stream context options to pass to the VMWarephp library in order to tune the https connection.
default_org_id The name of the default Organization in which the CIs (Servers, Hypervisors, Farms…) will be created Demo
To bypass SSL certificate validation (which is needed if your vSphere server runs with the default certificates installed by vSphere) add the folling lines in the params.local.xml file:

Other optional parameters


The file params.distrib.xml contains the default values for the parameters. Both files (params.distrib.xml and params.local.xml) use exactly the same format, but params.distrib.xml is considered as the reference and should remain unmodified.
Should you need to change the value of a parameter, copy and modify its definition in params.local.xml. The values in params.local.xml have precedence over the ones in params.distrib.xml

Minimal configuration

params.local.xml is at minimum, the file to edit to configure a collector.

And the following parameters must be set in this file:

Parameter Meaning Sample value
itop_login Login (user account) for connecting to iTop. Must have admin rights for executing the data synchro. admin
itop_password Password for the iTop account.
itop_url URL to the iTop Application https://localhost/itop

Optional parameters

The following parameters can be redefined to alter the default behavior of the collector:

Parameter Meaning Default value
max_chunk_size Maximum number of elements to process in one iteration (for upload and synchro in iTop). If there are more elements than this number, the process will automatically iterate. 1000
itop_synchro_timeout Timeout for waiting for the execution of one data synchro task (in seconds)- requires php_curl 600
stop_on_synchro_error Whether or not to stop when an error occurs during a synchronization (yes or no). no
console_log_level Level of ouput to the console. From -1 (none) to 9 (debug). 6 (info)
console_log_dateformat Logger timestamp format [Y-m-d H:i:s]
eventissue_log_level Level threshold to create event issues on remote iTop. From -1 (none) to 9 (debug). -1 (none juste like before)
curl_options When using cUrl to connect to the iTop Webservices the cUrl options can be specified in this section. The syntax is <CURLOPT_NAME_OF_THE_OPTION1>VALUE 1</CURLOPT_NAME_OF_THE_OPTION1> where VALUE_x are either:
The numeric value of the option,
or the string representation of the corresponding PHP “define” (case sensitive).
It is possible to define several php_curl options like in the example below
data_path New in 1.1.4 The path where to store the temporary files generated by the collector. You can use the special placeholder %APPROOT% to specify a path relative to the root folder of the collector. %APPROOT%/data
The following options might help if you're connecting using HTTPS:
Collectors are using synchro_import, but does not propagate yet date_format

Configuration for a SQL collector

The configuration parameters for the SQL Collectors are:

Parameter Meaning Default Value
sql_engine The PDO driver/engine to use for the database connection. mysql
sql_host The name or IP address of the database server to connect to. localhost
sql_database The name of the database to connect to. empty
sql_login The login to use when connecting to the database root
sql_password The password to use when connecting to the database n/a
sql_connection_string New in 1.0.8 The format of the PDO connection string. 3 placeholders are available inside the format string: %1$s = sql_engine, %2$s= sql_database and %3$s = sql_host %1$s:dbname=%2$s;host=%3$s
collector_class_query The query to run for the collector which PHP class is collector_class. For example : MyCollectorClass_query
collector_class_ignored_attributes New in 1.0.6 To take into account the possible variations of the data model, without re-writing a collector each time, it is possible to mark some of the collected attributes as “optional” so that the collector can run even if the corresponding attribute does not exist in the data model. Supply an array of attribute codes to ignore, here.
To specify a port number (or any other driver specific options), change the format of the sql_connection_string. For example: %1$s:dbname=%2$s;host=%3$s;port=3307

For versions prior to 1.0.8, to specify a port number (other than the default port), use the syntax host;port=xxxx for the sql_host parameter. Example: localhost;port=3307

Starting with version 1.0.10, the framework provides a new class of collector: MySQLCollector. This class is identical to SQLCollector except that it forces the retrieved data to be encoded in UTF-8 by issuing the SQL command SET NAMES 'utf8' at the beginning of the each connection to the database. To avoid any problem with the character set of the data, it is recommended to use this new class for all connections to a MySQL/MariaDB database.

Configuration for a JSON collector

Parameter Meaning
jsonfile Define relative or absolute path to the json file to parse for the collector which PHP class is collector collector_class. This parameter or jsonurl is mandatory
jsonurl The URL of json file to parse for the collector which PHP class is. This parameter or jsonpath is mandatory
jsonpost Xml of params to post with the url in order to get Json file <name_of_param>value</name_of_param>
command The CLI command to execute BEFORE parsing json file for the collector which PHP class is collector_class. This parameter is optional
path path in order to find data to synchronize in json separator is / and * replace any word by example aa/bb for {“aa”:{“bb”:{mydata},“cc”:“xxx”} and aa/ * /bb for {“aa”:{cc“:{“bb”:{mydata1}},”dd“:{“bb”:{mydata2}}}
fields xml which describes connection between name in json and name in itop <name_in_itop>name_in_json</name_in_json>
It can be a path as the path parameter, so include level /, * and index (number), when the structure has no key
defaults allow to specify itop fields for which we want to set fixed values. It can be used in combination with a mapping, for the case where a particular Blabla Site has no value for this field.

Configuration for a CSV collector

Inside your collector configuration section you can set below parameters:

Parameter Meaning Default Value
csv_file The csv file to be parsed by the collector. You can specify an URL, the full path of this file (/tmp/myfile.csv) or a relative path to the collector collector_class. This parameter is mandatory
command The CLI command to execute BEFORE reading/parsing csv file. This parameter is optional
encoding The csv file encoding. This parameter is optional UTF-8
separator The separator to use for the csv file to parse. This parameter is optional. Note: you can use the literal string TAB to specify that the separator is the ASCII character tab (0x09). ;
defaults for each synchro field you can specify a default value to be used during synchro step
fields This is a mapping section between data synchro fields and the one found in the CSV file.
ignored_columns This section describes which CSV fields you decide to ignore.
has_header Indicates whether there is CSV header that describes your column names or not. true

Brands, Models, OS Family and OS Version normalization

The values collected for Brands, Models and OS Family may be very variable because they came from non homogeneous sources (BIOS, operating system…). The data collector contains a simple mechanism to filter / normalize the values via a manual tuning, before importing them into iTop: a simple mapping table.

Creating the Mapping Table is an iterative process, since the table must be adapted when the collector encounters new values (new machine with a different BIOS, new operating system…)

Mapping tables are defined and maintained in the configuration file params.local.xml (you can copy an example definition from params.distrib.xml and ajust it at your will). brand_mapping is used for filtering the Brand values, model_mapping is used for Models, os_family_mapping is used for OS Families and os_version_mapping is used for OS Versions.

A mapping table is simply an ordered list of patterns and replacement strings. For each entry in the list, if the supplied value matches the pattern, it is replaced by the replacement string. The patterns are processed from the first one (top of the list) to the last one (bottom of the list). The processing stops after the first successful match.

The format of each entry in the mapping table is:



  • regular_expression is a PCRE regular expression to be matched against the input value,
  • replacement_string is the resulting value if the input value matches the regular expression.
  • Note: any character can be use as a delimiter around the regular expression, not only /. But the delimiter character can be present neither in the expression itself nor in the replacement string or the result will be undetermined.

The replacement string is the literal value to use, with the exception of placeholders in the form %1$s, %2$s… The placeholder %1$s corresponds to the part of the input string that matches the whole regular expression. Placeholders %2$s, %3$s corresponds to matching groups (i.e. parentheses) in the regular expression.

Example of a mapping table for the brands:

  <brand_mapping type="array">
    <!-- Syntax /pattern/replacement where:
      any delimiter can be used (not only /)
      but the delimiter cannot be present in the "replacement" string
      pattern is a RegExpr pattern
      replacement is a sprintf string in which:
          %1$s will be replaced by the whole matched text,
          %2$s will be replaced by the first matched group, if any group is defined in the RegExpr
          %3$s will be replaced by the second matched group, etc...
    <pattern>/Hewlett Packard/Hewlett-Packard</pattern>

The result of such a mapping table will be:

  • Any brand containing the letters IBM (case sensitive) will become exactly IBM
  • Any brand containing Hewlett Packard (case sensitive) will become exactly Hewlett-Packard (notice the added dash between Hewlett and Packard)
  • Any brand containing Hewlett-Packard (case sensitive) will become exactly Hewlett-Packard
  • Any brand containing the letters Dell (case sensitive) will become exactly Dell
Make sure that you keep the last (match all) item in the list to avoid loosing some values.

IPs and logical interfaces collection

The collector automatically detects if TeemIp is present on the remote iTop application (as a module or even as a stand-alone application). Should that be the case, then the following parameters may trigger IP addresses and logical interfaces collection.

<?xml version="1.0" encoding="UTF-8"?>
    <teemip_options type="hash">
Parameter Meaning Sample value
collect_ips Triggers IP addresses collection yes
default_ip_status Satus of newly created IP addresses allocated
manage_ipv6 Triggers IPv6 collection - not working yet no
manage_logical_interfaces Triggers logical interfaces collection as well as the addresses / interfaces links yes
At this stage, IPv6 are not collected. This is due to a limitation of the collector base which cannot handle such objects yet.

Configurable collectors

Starting with version 1.0.12 of the application, Server and Hypervisor collectors are configurable by adding extra definitions in the XMl parameter file.

This configuration contains two parts:

  1. The first part (under the <json> tag) allows to alter the definition of the Synchro Data Source (normally fixed by the .json file associated with the collector class). This is useful to synchronise a new field which was not synchronized by default, or to change a reconciliation rule on a field, etc… Any field under the attribute_list part of the JSON file can be modified by specifying a new value in the configuration.
  2. The second part (the <source> tag) defines the way to collect the data for the attribute. This tag must contain a (partial) PHP expression relative to the Hypervisor object (which is actually a HostSystem in the vSphere model)

Both parts of the configuration can be used independently (one can alter only the JSON or only the collection, or both).

The example below configures the collection of the “Serial Number” on Servers (from the otherIdentifyingInfo[EnclosureSerialNumberTag]) and also uses the collected serial number as the reconciliation key between Hypervisors and physical Servers (the field server_id).

<?xml version="1.0" encoding="UTF-8"?>
The special syntax with brackets in the <source> tag is currently only supported on the otherIdentifyingInfo property.


The execution of the command line will:

  1. Connect to iTop to create the Synchronization Data Sources (or check their definition if they already exist, updating them if needed)
  2. Connect to vSphere to collect the information about the Hypervisors, Farms, Virtual Machines
  3. Upload the collected data into iTop
  4. Synchronize the collected data with the existing iTop CIs.

To launch the data collection and synchronization with iTop, run the following command (from the root directory where the application is installed):

php exec.php

The following (optional) command line options are available:

Option Meaning default value
--config_file Specify the full path to the configuration file. The file conf/params.local.xml is used by default if this parameter is omitted. empty
--console_log_level=<level> Level of ouput to the console. From -1 (none) to 9 (debug). 6 (info)
--eventissue_log_level=<level> Level threshold to create event issues. From -1 (none) to 9 (debug). 6 (info)
--collect_only Run only the data collection, but do not synchronize the data with iTop false
--synchro_only Synchronizes the data previously collected (stored in the data directory) with iTop. Do not run the collection. false
--configure_only Check (and update if necessary) the synchronization data sources in iTop and exit. Do NOT run the collection or the synchronization
--max_chunk_size=<size> Maximum number of items to process in one pass, for preserving the memory of the system. If there are more items to process, the application will iterate. 1000
--help Usage mode to display exec.php help.
Dates in source data must use this format YYYY-MM-DD (hh:mm:ss)


If you have troubles connecting to the vSphere server, try the following troubleshooting steps:

  1. Check that the connection from the system running PHP to the vSphere server is actually possible. Use a command line tool like wget to connect to the vSphere server. For example if your vsphere_uri is, try:
    wget --no-check-certificate -O -

    If the connection does not succeed, there may be a firewall blocking your requests, or that vSphere is condifured to operate on a different port (for example 9443)… ask your IT department about it.

  2. Once the connection seem to go fine, configure the proper vsphere_uri value in conf/params.local.xml and, from the command line (in the collectors subdirectory) launch:
    php check_soap.php

    The expected output (with vsphere_uri = is:

    Connecting to
    Ok, the response looks like a valid SOAP response.
    --------------------- DEBUG ----------------
    The request returned:
    <?xml version="1.0" encoding="UTF-8"?>
    <soapenv:Envelope xmlns:soapenc=""
    <RetrieveServiceContentResponse xmlns="urn:vim25"><returnval><rootFolder type="Folder">group-d1</rootFolder><propertyCollector type="PropertyCollector">propertyCollector</propertyCollector><viewManager type="ViewManager">ViewManager</viewManager><about><name>VMware vCenter Server</name><fullName>VMware vCenter Server 4.1.0 build-345043</fullName><vendor>VMware, Inc.</vendor><version>4.1.0</version><build>345043</build><localeVersion>INTL</localeVersion><localeBuild>0</localeBuild><osType>win32-x86</osType><productLineId>vpx</productLineId><apiType>VirtualCenter</apiType><apiVersion>4.1</apiVersion></about><setting type="OptionManager">VpxSettings</setting><userDirectory type="UserDirectory">UserDirectory</userDirectory><sessionManager type="SessionManager">SessionManager</sessionManager><authorizationManager type="AuthorizationManager">AuthorizationManager</authorizationManager><perfManager type="PerformanceManager">PerfMgr</perfManager><scheduledTaskManager type="ScheduledTaskManager">ScheduledTaskManager</scheduledTaskManager><alarmManager type="AlarmManager">AlarmManager</alarmManager><eventManager type="EventManager">EventManager</eventManager><taskManager type="TaskManager">TaskManager</taskManager><extensionManager type="ExtensionManager">ExtensionManager</extensionManager><customizationSpecManager type="CustomizationSpecManager">CustomizationSpecManager</customizationSpecManager><customFieldsManager type="CustomFieldsManager">CustomFieldsManager</customFieldsManager><diagnosticManager type="DiagnosticManager">DiagMgr</diagnosticManager><licenseManager type="LicenseManager">LicenseManager</licenseManager><searchIndex type="SearchIndex">SearchIndex</searchIndex><fileManager type="FileManager">FileManager</fileManager><virtualDiskManager type="VirtualDiskManager">VirtualDiskManager</virtualDiskManager></returnval></RetrieveServiceContentResponse>

    If the result is not the expected one, check that your vSphere server is properly configured to run as HTTPS (which should be the default).

Data Collection Reference

Servers and Hypervisors

In the vSphere web services SDK, Hypervisors and physical Servers are represented by the same object HostSystem.

The information from the vSphere HostSystem object is imported in iTop into the Server object using the following mapping:

Field in iTop Source in vSphere
name HostSystem → name
org_id Constant value, supplied by the configuration file
brand_id The information from HostSystem → hardware → systemInfo → vendor is processed through the mapping table named brand_mapping
model_id The information from HostSystem → hardware → systemInfo → model is processed through the mapping table named model_mapping
cpu HostSystem → hardware → cpuInfo → numCpuPackages
ram HostSystem → hardware → memorySize divided by (1024*1024)
osfamily_id The information from HostSystem → config → product → name is processed through the mapping table named os_family_mapping
osversion_id The information from HostSystem → config → product → fullName is processed through the mapping table named os_version_mapping
status Constant value: active
managementip_id Foreign key to an IPAddress object, if IP collection is activated

The information from the vSphere HostSystem object is imported in iTop into the Hypervisor object using the following mapping:

Field in iTop Source in vSphere
name HostSystem → name
org_id Constant value, supplied by the configuration file
server_id HostSystem → name
The example used in the section Configurable Collectors shows how to collect the serial number of servers. Be aware that the information available in the property otherIdentifyingInfo seem to depend on the hardware manufacturer and/or the version of the hypervisor. Test on your systems before putting such a modification in production.


In the vSphere web services SDK, a Farm is represented by the object ClusterComputeResource.

The information from the vSphere ClusterComputeResource object is imported in iTop into the Farm object using the following mapping:

Field in iTop Source in vSphere
name ClusterComputeResource → name
org_id Constant value, supplied by the configuration file

The list of hypervisors belonging to a farm is collected via the property: ClusterComputeResource → host → name.

Virtual Machines

In the vSphere web services SDK, a Virtual Machine is represented by the object VirtualMachine. The information from the vSphere VirtualMachine object is imported in iTop into the VirtualMachine object using the following mapping:

Field in iTop Source in vSphere
name VirtualMachine → name
org_id Constant value, supplied by the configuration file
description VirtualMachine → config → annotation
cpu VirtualMachine → config → hardware → numCPU
ram VirtualMachine → config → hardware → memoryMB
virtualhost_id either the Farm (if not empty) or VirtualMachine → runtime → host → name
If TeemIp is NOT used
managementip VirtualMachine → guest → ipAddress
If TeemIp IS used and if IPs are collected
managementip_id Foreign key to an IPAddress object with ip set to VirtualMachine → guest → ipAddress

IPv4 Addresses

If enabled (TeemIp required), the information from the vSphere IPv4 addresses is imported in iTop into the IPv4Address object using the following mapping:

Field in iTop Source in vSphere
org_id Constant value, supplied by the configuration file
status Constant value, supplied by the configuration file
short_name VirtualMachine → guest → hostName
ip Virtual Machine: VirtualMachine → guest → ipAddress
Hypervisor: HostSystem → name

Logical Interfaces

If enabled (TeemIp required), the collector may register the logical interfaces attached to virtual machines. These are imported in iTop into the LogicalInterface objects using the following mapping:

Field in iTop Source in vSphere
macaddress VirtualMachine → guest → net → macAddress
name VirtualMachine → config → hardware → device → backing →
* network → name or
* opaqueNetworkId or
* deviceName or
* port
virtualmachine_id VirtualMachine → name
ip_list List of IP addresses attached to the interface
The ip_list attribute is synchronized through the dedicated synchro data source vSphere:lnkIPInterfaceToIPAddress.
extensions/vsphere-data-collector.txt · Last modified: 2023/04/07 12:32 (external edit)
Back to top
Contact us
